Quick Guide: Logging into Your Fargate Containers on AWS ECS

By Ramakrishna P

2 mins Read

AWS ECS (Elastic Container Service) is a powerful container management service that simplifies the process of running, managing, and scaling Docker containers on AWS. Connecting to ECS containers is a crucial step in the deployment process, allowing users to interact with their applications and services seamlessly. In this guide, we will explore how to connect to AWS ECS containers in a few straightforward steps.

STEP 1: Attach SSM Policy to the existing ECS Task IAM role

Create the below SSM policy and attach it to the ECS Task IAM role, this policy will allow connection to ECS task using Session Manager Service (SSM).

{

  "Version": "2012-10-17",

  "Statement":[
     {
        "Effect": "Allow",
        "Action": [
            "ssmmessages:CreateControlChannel",
            "ssmmessages:CreateDataChannel",
            "ssmmessages:OpenControlChannel",
            "ssmmessages:OpenDataChannel"
          ],
            "Resource": "*"
      }
   ]

}

Now create a new ECS Task IAM role with the above SSM policy and attach the role to the ECS task definition from dropdown as

STEP 2: Now on a remote machine from where we want to connect to the ECS container:

Install Session Manager Plugin

https://docs.aws.amazon.com/systems-manager/latest/userguide/session-manager-working-with-install-plugin.html

Now add the below IAM role policy for a User/AWS resource to execute ECS commands

{

  "Version": "2012-10-17",

  "Statement":[

     {
        "Effect": "Allow",
        "Action": [
            "ecs:ExecuteCommand",
            "ecs:DescribeTasks",
            "ecs:UpdateService",
            "iam:PassRole"
          ],
            "Resource": "*"
      }
   ]
}

STEP 3: Enable execute ECS Commands on existing ECS tasks running under a service

aws ecs update-service --cluster <cluster-name> --task-definition <task-definition-name> --enable-execute-command --service <service-name>

Below is the sample output, scroll down to find "enableExecuteCommand": true

Note: We need to Restart the ECS container which is already running, so that the execute command is set to True.

Verify Enable Execute Command Status on new task

aws ecs describe-tasks --cluster <cluster-name> --tasks <task-id>

Command to connect to ECS Fargate Container

aws ecs execute-command –cluster <cluster-name> --task <task-id> --container <container-name> --interactive --command "/bin/sh"
